Get your next Industrial, Medical or Automotive product design done faster, cheaper and with less uncertainty by using a System on Module

High-performance Apps

Opal-6 System on Module

NXP™ i.MX6

  • NXP i.MX6 System-on-Chip : 6 Options from Solo to QuadPlus
  • 1GBytes DDR3
  • 4GBytes eMMC Flash
  • 10/100/1000 Ethernet PHY
  • 2 x 168-pin connectors with almost all i.MX6 signals

more info about Opal-6 System on Module

Rich Applications + Real-time

Quartz System on Module

NXP™ Vybrid

  • NXP Vybrid VF6xx System-on-Chip
  • 256MBytes DDR3
  • 256MBytes NAND Flash
  • Dual 10/100 Ethernet PHYs*
  • 3.3V Single Supply Input
  • Boot Configuration Logic*
    *LGA version has single PHY and requires external boot logic or the on-chip fuses to be blown.
  • Quartz is only available through our Design License Programme

more info about Quartz System on Module

Low-power Industrial Apps

Topaz i.MX25 CPU Module

Topaz i.MX25

  • NXP i.MX25 System-on-Chip
  • 64MBytes Low-Power DDR RAM
  • 128MBytes NAND Flash
  • 10/100 Ethernet PHY

more info about Topaz i.MX25 CPU Module
